Java案例怎么实现原型模式？

Java原型模式实现案例

原型模式（Prototype Pattern）用于创建重复的对象，同时保证性能，它通过克隆现有对象来创建新对象,而不是通过new关键字。

基本原型模式实现

// 1. 实现Cloneable接口的原型类
public class Shape implements Cloneable {
    private String id;
    protected String type;
    public Shape(String id, String type) {
        this.id = id;
        this.type = type;
    }
    // 实现克隆方法
    @Override
    public Shape clone() throws CloneNotSupportedException {
        return (Shape) super.clone();
    }
    // getter和setter方法
    public String getId() { return id; }
    public void setId(String id) { this.id = id; }
    public String getType() { return type; }
    // 抽象方法，由子类实现
    public void draw() {
        System.out.println("Drawing " + type);
    }
}
// 2. 具体原型类
class Circle extends Shape {
    private int radius;
    public Circle(String id, int radius) {
        super(id, "Circle");
        this.radius = radius;
    }
    @Override
    public void draw() {
        System.out.println("Drawing Circle with radius: " + radius);
    }
    @Override
    public Circle clone() throws CloneNotSupportedException {
        return (Circle) super.clone();
    }
}
class Rectangle extends Shape {
    private int width;
    private int height;
    public Rectangle(String id, int width, int height) {
        super(id, "Rectangle");
        this.width = width;
        this.height = height;
    }
    @Override
    public void draw() {
        System.out.println("Drawing Rectangle " + width + "x" + height);
    }
    @Override
    public Rectangle clone() throws CloneNotSupportedException {
        return (Rectangle) super.clone();
    }
}
// 3. 使用原型模式
public class PrototypeDemo {
    public static void main(String[] args) throws CloneNotSupportedException {
        // 创建原始对象
        Circle originalCircle = new Circle("1", 10);
        originalCircle.draw();
        // 克隆对象
        Circle clonedCircle = originalCircle.clone();
        clonedCircle.setId("2");
        clonedCircle.draw();
        System.out.println("Original == Cloned? " + (originalCircle == clonedCircle));
        System.out.println("Original equals Cloned? " + originalCircle.equals(clonedCircle));
    }
}

深拷贝实现

当对象包含引用类型时,需要使用深拷贝：

import java.util.ArrayList;
import java.util.List;
class Employee implements Cloneable {
    private String name;
    private List<String> skills;
    private Address address;
    public Employee(String name) {
        this.name = name;
        this.skills = new ArrayList<>();
        this.address = new Address();
    }
    // 深拷贝实现
    @Override
    public Employee clone() throws CloneNotSupportedException {
        Employee cloned = (Employee) super.clone();
        // 深拷贝引用类型
        cloned.skills = new ArrayList<>(this.skills);
        cloned.address = this.address.clone();
        return cloned;
    }
    // 内部类
    static class Address implements Cloneable {
        private String city;
        private String street;
        @Override
        public Address clone() throws CloneNotSupportedException {
            return (Address) super.clone();
        }
        // getter/setter
        public String getCity() { return city; }
        public void setCity(String city) { this.city = city; }
        public String getStreet() { return street; }
        public void setStreet(String street) { this.street = street; }
    }
    // getter/setter
    public String getName() { return name; }
    public void setName(String name) { this.name = name; }
    public List<String> getSkills() { return skills; }
    public void setSkills(List<String> skills) { this.skills = skills; }
    public Address getAddress() { return address; }
}

原型管理器实现

import java.util.HashMap;
import java.util.Map;
class ShapeCache {
    private static Map<String, Shape> shapeMap = new HashMap<>();
    public static Shape getShape(String shapeId) {
        Shape cachedShape = shapeMap.get(shapeId);
        try {
            return cachedShape.clone();
        } catch (CloneNotSupportedException e) {
            e.printStackTrace();
            return null;
        }
    }
    // 加载初始数据
    public static void loadCache() {
        Circle circle = new Circle("1", 10);
        shapeMap.put(circle.getId(), circle);
        Rectangle rectangle = new Rectangle("2", 5, 8);
        shapeMap.put(rectangle.getId(), rectangle);
    }
}
// 使用原型管理器
public class PrototypeManagerDemo {
    public static void main(String[] args) {
        ShapeCache.loadCache();
        // 获取克隆对象
        Shape clonedCircle = ShapeCache.getShape("1");
        clonedCircle.draw();
        Shape clonedRectangle = ShapeCache.getShape("2");
        clonedRectangle.draw();
    }
}

序列化实现深拷贝

import java.io.*;
class SerializedObject implements Serializable {
    private static final long serialVersionUID = 1L;
    private String name;
    private transient int age;  // transient字段不会被序列化
    public SerializedObject(String name, int age) {
        this.name = name;
        this.age = age;
    }
    // 通过序列化实现深拷贝
    public SerializedObject deepClone() {
        try {
            // 序列化
            ByteArrayOutputStream bos = new ByteArrayOutputStream();
            ObjectOutputStream oos = new ObjectOutputStream(bos);
            oos.writeObject(this);
            oos.close();
            // 反序列化
            ByteArrayInputStream bis = new ByteArrayInputStream(bos.toByteArray());
            ObjectInputStream ois = new ObjectInputStream(bis);
            return (SerializedObject) ois.readObject();
        } catch (Exception e) {
            e.printStackTrace();
            return null;
        }
    }
    // getter/setter
    public String getName() { return name; }
    public void setName(String name) { this.name = name; }
    public int getAge() { return age; }
    public void setAge(int age) { this.age = age; }
}

实际应用示例：数据库连接池

import java.sql.Connection;
import java.sql.DriverManager;
import java.sql.SQLException;
class DatabaseConnection implements Cloneable {
    private String url;
    private String username;
    private String password;
    private Connection connection;
    public DatabaseConnection(String url, String username, String password) {
        this.url = url;
        this.username = username;
        this.password = password;
        createConnection();
    }
    private void createConnection() {
        try {
            connection = DriverManager.getConnection(url, username, password);
        } catch (SQLException e) {
            e.printStackTrace();
        }
    }
    @Override
    public DatabaseConnection clone() throws CloneNotSupportedException {
        // 浅拷贝连接配置，重新创建连接
        DatabaseConnection cloned = (DatabaseConnection) super.clone();
        cloned.createConnection();  // 创建新的数据库连接
        return cloned;
    }
    public Connection getConnection() {
        return connection;
    }
    public void close() {
        try {
            if (connection != null && !connection.isClosed()) {
                connection.close();
            }
        } catch (SQLException e) {
            e.printStackTrace();
        }
    }
}

关键要点总结

使用场景

• 创建对象成本高（数据库连接、大型对象）
• 系统需要独立于对象创建过程
• 需要避免使用构造方法（如需要动态配置）
• 对象有多个可预见的变体

原型模式在需要频繁创建相似对象时非常有用,特别是在对象创建成本较高时。
