如何用Python案例实现图像滤镜？

wen python案例 2026-06-18 260

本文目录导读：

如何用Python案例实现图像滤镜？

环境准备
基础滤镜实现
高级滤镜效果
完整示例：照片滤镜应用
实时滤镜（摄像头应用）
实用建议

我来介绍几个使用Python实现图像滤镜的完整案例,主要使用PIL(Pillow)和OpenCV库。

环境准备

首先安装必要的库：

pip install pillow opencv-python numpy

基础滤镜实现

1 灰度滤镜

from PIL import Image
import numpy as np
def grayscale_filter(image_path, output_path):
    """灰度滤镜 - 方法1：使用PIL内置方法"""
    img = Image.open(image_path)
    gray_img = img.convert('L')
    gray_img.save(output_path)
    return gray_img
def grayscale_filter_manual(image_path, output_path):
    """灰度滤镜 - 方法2：手动实现"""
    img = Image.open(image_path)
    pixels = np.array(img)
    # 加权平均法
    gray = np.dot(pixels[...,:3], [0.299, 0.587, 0.114])
    gray = gray.astype(np.uint8)
    result = Image.fromarray(gray)
    result.save(output_path)
    return result
# 使用示例
grayscale_filter('input.jpg', 'gray_output.jpg')

2 复古/怀旧滤镜

def vintage_filter(image_path, output_path):
    """复古怀旧滤镜"""
    img = Image.open(image_path)
    pixels = np.array(img)
    # 增加暖色调
    r, g, b = pixels[:,:,0], pixels[:,:,1], pixels[:,:,2]
    r = np.clip(r * 0.9 + 30, 0, 255).astype(np.uint8)
    g = np.clip(g * 0.85 + 20, 0, 255).astype(np.uint8)
    b = np.clip(b * 0.75, 0, 255).astype(np.uint8)
    result = np.stack([r, g, b], axis=2)
    result = Image.fromarray(result)
    result.save(output_path)
    return result

3 模糊滤镜

from PIL import ImageFilter
def blur_filter(image_path, output_path, radius=5):
    """高斯模糊滤镜"""
    img = Image.open(image_path)
    # 使用PIL内置高斯模糊
    blurred = img.filter(ImageFilter.GaussianBlur(radius=radius))
    blurred.save(output_path)
    return blurred
def motion_blur(image_path, output_path, size=10):
    """运动模糊效果"""
    img = Image.open(image_path)
    # 创建运动模糊核
    kernel = np.zeros((size, size))
    kernel[int((size-1)/2), :] = np.ones(size)
    kernel = kernel / size
    # 应用卷积
    from scipy import signal
    pixels = np.array(img)
    if len(pixels.shape) == 3:
        result = np.zeros_like(pixels)
        for i in range(3):
            result[:,:,i] = signal.convolve2d(
                pixels[:,:,i], kernel, mode='same', boundary='symm'
            )
    else:
        result = signal.convolve2d(pixels, kernel, mode='same', boundary='symm')
    result = result.astype(np.uint8)
    result = Image.fromarray(result)
    result.save(output_path)
    return result

4 边缘检测滤镜

def edge_detection(image_path, output_path):
    """边缘检测滤镜"""
    # 方法1：使用PIL
    img = Image.open(image_path).convert('L')
    # 查找边缘
    edges = img.filter(ImageFilter.FIND_EDGES)
    edges.save(output_path)
    # 方法2：使用Sobel算子
    img_array = np.array(img)
    # Sobel算子
    sobel_x = np.array([[-1, 0, 1], [-2, 0, 2], [-1, 0, 1]])
    sobel_y = np.array([[-1, -2, -1], [0, 0, 0], [1, 2, 1]])
    from scipy import signal
    grad_x = signal.convolve2d(img_array, sobel_x, mode='same', boundary='symm')
    grad_y = signal.convolve2d(img_array, sobel_y, mode='same', boundary='symm')
    # 计算梯度幅值
    gradient = np.sqrt(grad_x**2 + grad_y**2)
    gradient = (gradient / gradient.max() * 255).astype(np.uint8)
    result = Image.fromarray(gradient)
    result.save('edge_sobel_' + output_path)
    return result

高级滤镜效果

1 卡通效果滤镜

import cv2
def cartoon_filter(image_path, output_path):
    """卡通效果滤镜"""
    # 读取图像
    img = cv2.imread(image_path)
    img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
    # 1. 边缘检测
    gray = cv2.cvtColor(img, cv2.COLOR_RGB2GRAY)
    gray = cv2.medianBlur(gray, 5)
    edges = cv2.adaptiveThreshold(
        gray, 255, cv2.ADAPTIVE_THRESH_MEAN_C,
        cv2.THRESH_BINARY, 9, 9
    )
    # 2. 颜色量化
    color = cv2.bilateralFilter(img, 9, 300, 300)
    # 3. 组合边缘和颜色
    cartoon = cv2.bitwise_and(color, color, mask=edges)
    result = Image.fromarray(cartoon)
    result.save(output_path)
    return result

2 油画效果滤镜

def oil_painting_effect(image_path, output_path, radius=5, intensity=20):
    """油画效果滤镜"""
    img = cv2.imread(image_path)
    img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
    # 使用OpenCV的油画效果函数
    oil = cv2.xphoto.oilPainting(img, radius, intensity)
    result = Image.fromarray(oil)
    result.save(output_path)
    return result

3 水彩效果滤镜

def watercolor_effect(image_path, output_path):
    """水彩效果滤镜"""
    img = cv2.imread(image_path)
    img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
    # 1. 中值滤波去噪
    filtered = cv2.medianBlur(img, 7)
    # 2. 双边滤波保留边缘
    filtered = cv2.bilateralFilter(filtered, 15, 75, 75)
    # 3. 增加纹理效果
    kernel = np.array([[0, -1, 0], [-1, 5, -1], [0, -1, 0]])
    sharpened = cv2.filter2D(filtered, -1, kernel)
    result = Image.fromarray(sharpened)
    result.save(output_path)
    return result

完整示例：照片滤镜应用

class PhotoFilter:
    """照片滤镜类"""
    def __init__(self, image_path):
        self.image_path = image_path
        self.img = Image.open(image_path)
        self.pixels = np.array(self.img)
    def apply_filters(self, filters_dict, output_prefix="filtered"):
        """应用多个滤镜并保存"""
        results = {}
        for name, params in filters_dict.items():
            if hasattr(self, f"_{name}_filter"):
                method = getattr(self, f"_{name}_filter")
                result = method(**params)
                output_path = f"{output_prefix}_{name}.jpg"
                result.save(output_path)
                results[name] = output_path
        return results
    def _warm_filter(self, intensity=1.2):
        """暖色调滤镜"""
        pixels = self.pixels.copy()
        pixels[:,:,0] = np.clip(pixels[:,:,0] * intensity, 0, 255)
        pixels[:,:,1] = np.clip(pixels[:,:,1] * (intensity - 0.1), 0, 255)
        return Image.fromarray(pixels.astype(np.uint8))
    def _cool_filter(self, intensity=1.2):
        """冷色调滤镜"""
        pixels = self.pixels.copy()
        pixels[:,:,2] = np.clip(pixels[:,:,2] * intensity, 0, 255)
        return Image.fromarray(pixels.astype(np.uint8))
    def _sepia_filter(self, depth=30):
        """棕褐色滤镜"""
        pixels = self.pixels.copy()
        r, g, b = pixels[:,:,0], pixels[:,:,1], pixels[:,:,2]
        # 棕褐色转换
        tr = 0.393 * r + 0.769 * g + 0.189 * b
        tg = 0.349 * r + 0.686 * g + 0.168 * b
        tb = 0.272 * r + 0.534 * g + 0.131 * b
        pixels[:,:,0] = np.clip(tr + depth, 0, 255)
        pixels[:,:,1] = np.clip(tg + depth/2, 0, 255)
        pixels[:,:,2] = np.clip(tb, 0, 255)
        return Image.fromarray(pixels.astype(np.uint8))
# 使用示例
if __name__ == "__main__":
    # 初始化滤镜类
    filter_app = PhotoFilter("input.jpg")
    # 应用多种滤镜
    filters = {
        "warm": {"intensity": 1.3},
        "cool": {"intensity": 1.4},
        "sepia": {"depth": 40}
    }
    results = filter_app.apply_filters(filters)
    print("生成的滤镜效果：", results)

实时滤镜（摄像头应用）

import cv2
def realtime_filter():
    """实时摄像头滤镜"""
    cap = cv2.VideoCapture(0)
    filters = {
        'original': lambda img: img,
        'gray': lambda img: cv2.cvtColor(cv2.cvtColor(img, cv2.COLOR_BGR2GRAY), cv2.COLOR_GRAY2BGR),
        'edge': lambda img: cv2.cvtColor(cv2.Canny(img, 100, 200), cv2.COLOR_GRAY2BGR),
        'blur': lambda img: cv2.GaussianBlur(img, (15, 15), 0)
    }
    current_filter = 'original'
    while True:
        ret, frame = cap.read()
        if not ret:
            break
        # 应用滤镜
        filtered = filters[current_filter](frame)
        # 显示滤镜名称
        cv2.putText(filtered, f"Filter: {current_filter}",
                   (10, 30), cv2.FONT_HERSHEY_SIMPLEX, 0.7, (0, 255, 0), 2)
        cv2.imshow('Camera Filter', filtered)
        key = cv2.waitKey(1) & 0xFF
        # 按键切换滤镜
        if key == ord('q'):
            break
        elif key == ord('1'):
            current_filter = 'original'
        elif key == ord('2'):
            current_filter = 'gray'
        elif key == ord('3'):
            current_filter = 'edge'
        elif key == ord('4'):
            current_filter = 'blur'
    cap.release()
    cv2.destroyAllWindows()
