Java Sentinel案例如何整合

wen java案例 2026-06-28 242

本文目录导读：

Java Sentinel案例如何整合

Spring Boot 整合 Sentinel
Spring Cloud 整合 Sentinel
网关整合 Sentinel
整合 Sentinel 控制台
参数设计最佳实践
监控指标收集

我来详细介绍Java Sentinel与常见框架的整合案例。

Spring Boot 整合 Sentinel

Maven依赖配置

<!-- Sentinel 核心依赖 -->
<dependency>
    <groupId>com.alibaba.csp</groupId>
    <artifactId>sentinel-core</artifactId>
    <version>1.8.6</version>
</dependency>
<!-- Spring Boot 整合 -->
<dependency>
    <groupId>com.alibaba.csp</groupId>
    <artifactId>sentinel-spring-boot-starter</artifactId>
    <version>1.8.6</version>
</dependency>
<!-- 控制台支持 -->
<dependency>
    <groupId>com.alibaba.csp</groupId>
    <artifactId>sentinel-transport-simple-http</artifactId>
    <version>1.8.6</version>
</dependency>

配置文件 application.yml

spring:
  application:
    name: sentinel-demo
  cloud:
    sentinel:
      transport:
        dashboard: localhost:8080  # Sentinel控制台地址
        port: 8719  # 与Dashboard通信的端口
      eager: true  # 懒加载改为true，启动即连接控制台
server:
  port: 8081

基础使用示例

@RestController
@Slf4j
public class SentinelController {
    // 1. 使用注解方式
    @GetMapping("/test")
    @SentinelResource(value = "test-resource",
                      blockHandler = "handleBlock",
                      fallback = "handleFallback")
    public String test() {
        // 模拟业务逻辑
        if (Math.random() > 0.5) {
            throw new RuntimeException("业务异常");
        }
        return "Success";
    }
    // 限流处理
    public String handleBlock(BlockException ex) {
        log.warn("请求被限流: {}", ex.getMessage());
        return "请求过于频繁，请稍后重试";
    }
    // 熔断降级处理
    public String handleFallback(Throwable t) {
        log.error("业务异常: {}", t.getMessage());
        return "服务暂不可用，请稍后重试";
    }
    // 2. 编程式方式
    @GetMapping("/programmatic")
    public String programmatic() {
        try (Entry entry = SphU.entry("programmatic-resource")) {
            // 业务逻辑
            return "编程式限流控制成功";
        } catch (BlockException ex) {
            return "请求被限流";
        }
    }
    // 3. 热点参数限流
    @GetMapping("/hot/{id}")
    @SentinelResource(value = "hot-resource",
                      blockHandler = "handleHotBlock")
    public String hotParam(@PathVariable String id) {
        return "热点参数: " + id;
    }
    public String handleHotBlock(String id, BlockException ex) {
        return "热点参数 " + id + " 触发限流";
    }
}

自定义资源配置

@Component
@PostConstruct
public class SentinelRuleConfig {
    @PostConstruct
    public void initRules() {
        // 1. 流控规则
        List<FlowRule> flowRules = new ArrayList<>();
        FlowRule flowRule = new FlowRule();
        flowRule.setResource("test-resource");
        flowRule.setGrade(RuleConstant.FLOW_GRADE_QPS);  // QPS模式
        flowRule.setCount(10);  // 阈值为10
        flowRule.setControlBehavior(RuleConstant.CONTROL_BEHAVIOR_WARM_UP);  // 预热模式
        flowRule.setWarmUpPeriodSec(10);  // 预热时间10秒
        flowRules.add(flowRule);
        FlowRuleManager.loadRules(flowRules);
        // 2. 降级规则
        List<DegradeRule> degradeRules = new ArrayList<>();
        DegradeRule degradeRule = new DegradeRule();
        degradeRule.setResource("test-resource");
        degradeRule.setGrade(RuleConstant.DEGRADE_GRADE_RT);  // 响应时间模式
        degradeRule.setCount(100);  // 平均响应时间超过100ms
        degradeRule.setTimeWindow(10);  // 熔断时间10秒
        degradeRules.add(degradeRule);
        DegradeRuleManager.loadRules(degradeRules);
        // 3. 系统规则
        List<SystemRule> systemRules = new ArrayList<>();
        SystemRule systemRule = new SystemRule();
        systemRule.setHighestSystemLoad(10.0);  // 最大系统负载
        systemRule.setAvgRt(100);  // 平均响应时间
        systemRule.setMaxThread(1000);  // 最大线程数
        systemRules.add(systemRule);
        SystemRuleManager.loadRules(systemRules);
        // 4. 热点参数规则
        List<ParamFlowRule> paramFlowRules = new ArrayList<>();
        ParamFlowRule paramFlowRule = new ParamFlowRule("hot-resource");
        paramFlowRule.setCount(5);  // 每秒最多5次
        paramFlowRule.setDurationInSec(1);
        // 设置特定参数值例外
        ParamFlowItem item = new ParamFlowItem();
        item.setClassType(String.class.getName());
        item.setCount(100);  // 特定参数值阈值更高
        item.setObject("special");
        paramFlowRule.setParamFlowItemList(Collections.singletonList(item));
        paramFlowRules.add(paramFlowRule);
        ParamFlowRuleManager.loadRules(paramFlowRules);
    }
}

Spring Cloud 整合 Sentinel

依赖配置

<dependency>
    <groupId>com.alibaba.cloud</groupId>
    <artifactId>spring-cloud-starter-alibaba-sentinel</artifactId>
    <version>2021.0.5.0</version>
</dependency>
<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-openfeign</artifactId>
</dependency>

Feign整合

// Feign客户端
@FeignClient(name = "service-provider", fallback = ProductServiceFallback.class)
public interface ProductService {
    @PostMapping("/product/update")
    @SentinelResource(value = "update-product",
                      blockHandler = "handleBlock",
                      fallback = "handleFallback")
    Result updateProduct(@RequestBody Product product);
}
// 熔断降级实现
@Component
public class ProductServiceFallback implements ProductService {
    @Override
    public Result updateProduct(Product product) {
        return Result.error("服务熔断，暂时无法更新商品");
    }
}
// Feign配置
@Configuration
public class FeignConfiguration {
    @Bean
    public RequestInterceptor requestInterceptor() {
        return template -> {
            // 传递用户信息
            template.header("userId", "123456");
        };
    }
}

RestTemplate整合

@Configuration
public class RestTemplateConfig {
    @Bean
    @LoadBalanced
    @SentinelRestTemplate(
        blockHandlerClass = SentinelHandler.class,
        blockHandler = "handleException",
        fallbackClass = SentinelHandler.class,
        fallback = "handleError"
    )
    public RestTemplate restTemplate() {
        return new RestTemplate();
    }
}
// 处理器类
public class SentinelHandler {
    // 限流处理
    public static String handleException(String url, BlockException ex) {
        return "服务限流: " + ex.getMessage();
    }
    // 熔断降级
    public static String handleError(String url, Throwable t) {
        return "服务降级: " + t.getMessage();
    }
}

网关整合 Sentinel

Gateway整合

<dependency>
    <groupId>com.alibaba.cloud</groupId>
    <artifactId>spring-cloud-alibaba-sentinel-gateway</artifactId>
    <version>2021.0.5.0</version>
</dependency>

@Configuration
public class GatewayConfig {
    @PostConstruct
    public void initGatewayRules() {
        // API分组限流
        Set<ApiDefinition> apiDefinitions = new HashSet<>();
        ApiDefinition api = new ApiDefinition("product-api")
            .setPredicateItems(new HashSet<ApiPredicateItem>() {{
                add(new ApiPathPredicateItem()
                    .setPattern("/product/**")
                    .setMatchStrategy(SentinelGatewayConstants.URL_MATCH_STRATEGY_PREFIX));
            }});
        apiDefinitions.add(api);
        GatewayApiDefinitionManager.loadApiDefinitions(apiDefinitions);
        // 网关流控规则
        Set<GatewayFlowRule> rules = new HashSet<>();
        GatewayFlowRule rule = new GatewayFlowRule("product-api")
            .setCount(100)
            .setIntervalSec(1);
        rules.add(rule);
        GatewayRuleManager.loadRules(rules);
    }
}

整合 Sentinel 控制台

启动 Sentinel 控制台

# 下载控制台JAR
wget https://github.com/alibaba/Sentinel/releases/download/1.8.6/sentinel-dashboard-1.8.6.jar
# 启动控制台
java -Dserver.port=8080 -Dcsp.sentinel.dashboard.server=localhost:8080 -jar sentinel-dashboard-1.8.6.jar

配置推送 Nacos（生产环境）

spring:
  cloud:
    sentinel:
      datasource:
        ds1:
          nacos:
            server-addr: localhost:8848
            data-id: ${spring.application.name}-sentinel-rules
            group-id: DEFAULT_GROUP
            data-type: json
            rule-type: flow  # 规则类型

// Nacos监听器，实现动态规则推送
@Component
public class NacosConfigListener {
    @PostConstruct
    public void init() throws Exception {
        // 监听Nacos配置变化
        String dataId = "sentinel-rules";
        String group = "DEFAULT_GROUP";
        ConfigService configService = NacosFactory.createConfigService("localhost:8848");
        configService.addListener(dataId, group, new Listener() {
            @Override
            public void receiveConfigInfo(String configInfo) {
                // 解析配置，更新规则
                List<FlowRule> rules = JSON.parseArray(configInfo, FlowRule.class);
                FlowRuleManager.loadRules(rules);
            }
            @Override
            public Executor getExecutor() {
                return null;
            }
        });
    }
}

参数设计最佳实践

public class SentinelBlockHandler {
    // 统一异常处理
    @ExceptionHandler(BlockException.class)
    @ResponseStatus(HttpStatus.TOO_MANY_REQUESTS)
    public Result handleBlockException(BlockException e) {
        Result result = new Result();
        result.setCode(429);
        result.setMessage("系统繁忙，请稍后重试");
        // 记录限流日志
        log.warn("Sentinel限流: resource={}, rule={}",
                 e.getRule().getResource(), e.getRule());
        return result;
    }
    // 自定义限流逻辑
    public static Result handleBlockByParam(String param, BlockException ex) {
        // 针对不同参数的降级策略
        Map<String, Object> data = new HashMap<>();
        data.put("param", param);
        data.put("fallback", true);
        return Result.error(data, "限流降级");
    }
}

监控指标收集

@Component
public class SentinelMetricsCollector {
    @Scheduled(fixedRate = 60000)  // 每分钟收集一次
    public void collectMetrics() {
        // 获取所有资源的统计信息
        Map<ResourceWrapper, ClusterNode> clusterNodes =
            ClusterBuilderSlot.getClusterNodeMap();
        for (Map.Entry<ResourceWrapper, ClusterNode> entry :
             clusterNodes.entrySet()) {
            ClusterNode node = entry.getValue();
            Metrics metrics = new Metrics();
            metrics.setResource(entry.getKey().getName());
            metrics.setPassQps(node.passQps());
            metrics.setBlockQps(node.blockQps());
            metrics.setExceptionQps(node.exceptionQps());
            metrics.setAvgRt(node.avgRt());
            metrics.setCurThreadNum(node.curThreadNum());
            // 发送到监控系统（Prometheus、Grafana等）
            sendToMonitorSystem(metrics);
        }
    }
}

这个整合案例涵盖了 Sentinel 在 Spring Boot、Spring Cloud、Gateway 等主流框架中的使用，包含了规则配置、熔断降级、限流控制、控制台整合等核心功能。
