Java Boot整合MyBatis案例实操

wen java案例 23

Java Boot整合MyBatis案例实操

本文将演示如何使用Spring Boot整合MyBatis框架,实现完整的CRUD操作。

Java Boot整合MyBatis案例实操

环境准备

1 技术版本

  • JDK 1.8+
  • Spring Boot 2.3.x
  • MyBatis 3.5.x
  • MySQL 5.7+
  • Maven 3.6+

创建项目

1 使用Spring Initializr创建项目

通过 https://start.spring.io/ 或IDE创建项目,选择以下依赖：

  • Spring Web
  • MyBatis Framework
  • MySQL Driver

2 完整pom.xml依赖

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.3.12.RELEASE</version>
        <relativePath/>
    </parent>
    <groupId>com.example</groupId>
    <artifactId>mybatis-demo</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>mybatis-demo</name>
    <properties>
        <java.version>1.8</java.version>
    </properties>
    <dependencies>
        <!-- Spring Boot Web -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <!-- MyBatis -->
        <dependency>
            <groupId>org.mybatis.spring.boot</groupId>
            <artifactId>mybatis-spring-boot-starter</artifactId>
            <version>2.1.4</version>
        </dependency>
        <!-- MySQL -->
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <scope>runtime</scope>
        </dependency>
        <!-- 分页插件 -->
        <dependency>
            <groupId>com.github.pagehelper</groupId>
            <artifactId>pagehelper-spring-boot-starter</artifactId>
            <version>1.3.0</version>
        </dependency>
        <!-- Lombok -->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <!-- 测试 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>
    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

数据库准备

1 创建数据库和表

CREATE DATABASE IF NOT EXISTS mybatis_demo DEFAULT CHARACTER SET utf8mb4;
USE mybatis_demo;
CREATE TABLE t_user (
    id INT PRIMARY KEY AUTO_INCREMENT,
    username VARCHAR(50) NOT NULL,
    password VARCHAR(100) NOT NULL,
    email VARCHAR(100),
    phone VARCHAR(20),
    create_time DATETIME DEFAULT CURRENT_TIMESTAMP,
    update_time DATETIME DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4;
-- 插入测试数据
INSERT INTO t_user (username, password, email, phone) VALUES
('admin', '123456', 'admin@example.com', '13800138000'),
('zhangsan', 'abc123', 'zhangsan@example.com', '13900139000'),
('lisi', 'def456', 'lisi@example.com', '13700137000');

项目配置

1 application.yml配置

server:
  port: 8080
spring:
  datasource:
    driver-class-name: com.mysql.cj.jdbc.Driver
    url: jdbc:mysql://localhost:3306/mybatis_demo?useUnicode=true&characterEncoding=utf-8&serverTimezone=Asia/Shanghai&useSSL=false
    username: root
    password: root
    hikari:
      minimum-idle: 5
      maximum-pool-size: 20
      idle-timeout: 30000
      max-lifetime: 1800000
      connection-timeout: 30000
mybatis:
  mapper-locations: classpath:mapper/*.xml
  type-aliases-package: com.example.mybatisdemo.entity
  configuration:
    map-underscore-to-camel-case: true
    log-impl: org.apache.ibatis.logging.stdout.StdOutImpl
# 分页配置
pagehelper:
  helper-dialect: mysql
  reasonable: true
  support-methods-arguments: true
  params: count=countSql

代码实现

1 实体类

package com.example.mybatisdemo.entity;
import lombok.Data;
import java.time.LocalDateTime;
@Data
public class User {
    private Integer id;
    private String username;
    private String password;
    private String email;
    private String phone;
    private LocalDateTime createTime;
    private LocalDateTime updateTime;
}

2 Mapper接口

package com.example.mybatisdemo.mapper;
import com.example.mybatisdemo.entity.User;
import org.apache.ibatis.annotations.Mapper;
import java.util.List;
@Mapper
public interface UserMapper {
    // 根据ID查询
    User findById(Integer id);
    // 查询所有用户
    List<User> findAll();
    // 根据用户名模糊查询
    List<User> findByUsername(String username);
    // 新增用户
    int insert(User user);
    // 更新用户
    int update(User user);
    // 删除用户
    int deleteById(Integer id);
    // 批量插入
    int batchInsert(List<User> users);
    // 统计总数
    long count();
}

3 Mapper XML文件

创建 src/main/resources/mapper/UserMapper.xml：

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.example.mybatisdemo.mapper.UserMapper">
    <resultMap id="BaseResultMap" type="User">
        <id column="id" property="id"/>
        <result column="username" property="username"/>
        <result column="password" property="password"/>
        <result column="email" property="email"/>
        <result column="phone" property="phone"/>
        <result column="create_time" property="createTime"/>
        <result column="update_time" property="updateTime"/>
    </resultMap>
    <sql id="Base_Column_List">
        id, username, password, email, phone, create_time, update_time
    </sql>
    <!-- 根据ID查询 -->
    <select id="findById" parameterType="java.lang.Integer" resultMap="BaseResultMap">
        SELECT
        <include refid="Base_Column_List"/>
        FROM t_user
        WHERE id = #{id}
    </select>
    <!-- 查询所有 -->
    <select id="findAll" resultMap="BaseResultMap">
        SELECT
        <include refid="Base_Column_List"/>
        FROM t_user
        ORDER BY id DESC
    </select>
    <!-- 根据用户名模糊查询 -->
    <select id="findByUsername" parameterType="java.lang.String" resultMap="BaseResultMap">
        SELECT
        <include refid="Base_Column_List"/>
        FROM t_user
        WHERE username LIKE CONCAT('%', #{username}, '%')
    </select>
    <!-- 新增用户 -->
    <insert id="insert" parameterType="User" useGeneratedKeys="true" keyProperty="id">
        INSERT INTO t_user (username, password, email, phone)
        VALUES (#{username}, #{password}, #{email}, #{phone})
    </insert>
    <!-- 更新用户 -->
    <update id="update" parameterType="User">
        UPDATE t_user
        <set>
            <if test="username != null">username = #{username},</if>
            <if test="password != null">password = #{password},</if>
            <if test="email != null">email = #{email},</if>
            <if test="phone != null">phone = #{phone}</if>
        </set>
        WHERE id = #{id}
    </update>
    <!-- 删除用户 -->
    <delete id="deleteById" parameterType="java.lang.Integer">
        DELETE FROM t_user WHERE id = #{id}
    </delete>
    <!-- 批量插入 -->
    <insert id="batchInsert" parameterType="java.util.List">
        INSERT INTO t_user (username, password, email, phone)
        VALUES
        <foreach collection="list" item="item" separator=",">
            (#{item.username}, #{item.password}, #{item.email}, #{item.phone})
        </foreach>
    </insert>
    <!-- 统计总数 -->
    <select id="count" resultType="java.lang.Long">
        SELECT COUNT(*) FROM t_user
    </select>
</mapper>

4 Service层

package com.example.mybatisdemo.service;
import com.example.mybatisdemo.entity.User;
import com.example.mybatisdemo.mapper.UserMapper;
import com.github.pagehelper.PageHelper;
import com.github.pagehelper.PageInfo;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import org.springframework.transaction.annotation.Transactional;
import java.util.List;
@Service
public class UserService {
    @Autowired
    private UserMapper userMapper;
    public User findById(Integer id) {
        return userMapper.findById(id);
    }
    public List<User> findAll() {
        return userMapper.findAll();
    }
    // 分页查询
    public PageInfo<User> findByPage(Integer pageNum, Integer pageSize) {
        PageHelper.startPage(pageNum, pageSize);
        List<User> users = userMapper.findAll();
        return new PageInfo<>(users);
    }
    public List<User> findByUsername(String username) {
        return userMapper.findByUsername(username);
    }
    @Transactional
    public int insert(User user) {
        return userMapper.insert(user);
    }
    @Transactional
    public int update(User user) {
        return userMapper.update(user);
    }
    @Transactional
    public int deleteById(Integer id) {
        return userMapper.deleteById(id);
    }
    @Transactional
    public int batchInsert(List<User> users) {
        return userMapper.batchInsert(users);
    }
    public long count() {
        return userMapper.count();
    }
}

5 Controller层

package com.example.mybatisdemo.controller;
import com.example.mybatisdemo.entity.User;
import com.example.mybatisdemo.service.UserService;
import com.github.pagehelper.PageInfo;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.http.ResponseEntity;
import org.springframework.web.bind.annotation.*;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
@RestController
@RequestMapping("/api/users")
public class UserController {
    @Autowired
    private UserService userService;
    // 获取所有用户
    @GetMapping
    public ResponseEntity<List<User>> getAllUsers() {
        List<User> users = userService.findAll();
        return ResponseEntity.ok(users);
    }
    // 分页查询
    @GetMapping("/page")
    public ResponseEntity<PageInfo<User>> getUsersByPage(
            @RequestParam(defaultValue = "1") Integer pageNum,
            @RequestParam(defaultValue = "10") Integer pageSize) {
        PageInfo<User> pageInfo = userService.findByPage(pageNum, pageSize);
        return ResponseEntity.ok(pageInfo);
    }
    // 根据ID查询
    @GetMapping("/{id}")
    public ResponseEntity<User> getUserById(@PathVariable Integer id) {
        User user = userService.findById(id);
        if (user == null) {
            return ResponseEntity.notFound().build();
        }
        return ResponseEntity.ok(user);
    }
    // 根据用户名搜索
    @GetMapping("/search")
    public ResponseEntity<List<User>> searchUsers(@RequestParam String username) {
        List<User> users = userService.findByUsername(username);
        return ResponseEntity.ok(users);
    }
    // 新增用户
    @PostMapping
    public ResponseEntity<Map<String, Object>> createUser(@RequestBody User user) {
        int result = userService.insert(user);
        Map<String, Object> response = new HashMap<>();
        response.put("success", result > 0);
        response.put("id", user.getId());
        response.put("message", result > 0 ? "创建成功" : "创建失败");
        return ResponseEntity.ok(response);
    }
    // 更新用户
    @PutMapping("/{id}")
    public ResponseEntity<Map<String, Object>> updateUser(
            @PathVariable Integer id, @RequestBody User user) {
        user.setId(id);
        int result = userService.update(user);
        Map<String, Object> response = new HashMap<>();
        response.put("success", result > 0);
        response.put("message", result > 0 ? "更新成功" : "更新失败");
        return ResponseEntity.ok(response);
    }
    // 删除用户
    @DeleteMapping("/{id}")
    public ResponseEntity<Map<String, Object>> deleteUser(@PathVariable Integer id) {
        int result = userService.deleteById(id);
        Map<String, Object> response = new HashMap<>();
        response.put("success", result > 0);
        response.put("message", result > 0 ? "删除成功" : "删除失败");
        return ResponseEntity.ok(response);
    }
    // 批量插入
    @PostMapping("/batch")
    public ResponseEntity<Map<String, Object>> batchInsert(@RequestBody List<User> users) {
        int result = userService.batchInsert(users);
        Map<String, Object> response = new HashMap<>();
        response.put("success", result > 0);
        response.put("count", result);
        response.put("message", result > 0 ? "批量插入成功" : "批量插入失败");
        return ResponseEntity.ok(response);
    }
    // 统计用户总数
    @GetMapping("/count")
    public ResponseEntity<Map<String, Object>> getUserCount() {
        long count = userService.count();
        Map<String, Object> response = new HashMap<>();
        response.put("count", count);
        return ResponseEntity.ok(response);
    }
}

6 启动类

package com.example.mybatisdemo;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
@SpringBootApplication
public class MybatisDemoApplication {
    public static void main(String[] args) {
        SpringApplication.run(MybatisDemoApplication.class, args);
    }
}

API测试

1 使用curl测试

# 获取所有用户
curl http://localhost:8080/api/users
# 分页查询
curl "http://localhost:8080/api/users/page?pageNum=1&pageSize=5"
# 根据ID查询
curl http://localhost:8080/api/users/1
# 搜索用户
curl "http://localhost:8080/api/users/search?username=admin"
# 新增用户
curl -X POST http://localhost:8080/api/users \
  -H "Content-Type: application/json" \
  -d '{"username":"wangwu","password":"654321","email":"wangwu@example.com","phone":"13600136000"}'
# 更新用户
curl -X PUT http://localhost:8080/api/users/1 \
  -H "Content-Type: application/json" \
  -d '{"username":"admin_new","email":"admin_new@example.com"}'
# 删除用户
curl -X DELETE http://localhost:8080/api/users/3
# 批量插入
curl -X POST http://localhost:8080/api/users/batch \
  -H "Content-Type: application/json" \
  -d '[
    {"username":"user1","password":"123","email":"user1@test.com"},
    {"username":"user2","password":"456","email":"user2@test.com"}
  ]'
# 统计用户总数
curl http://localhost:8080/api/users/count

2 使用Postman测试

  1. 打开Postman
  2. 导入上述API接口
  3. 逐个测试CRUD操作

常见问题解决

1 数据库连接问题

错误：Communications link failure
解决：检查MySQL服务是否启动，连接配置是否正确

2 Mapper找不到

错误：Invalid bound statement (not found)
解决：检查application.yml中mapper-locations路径是否正确
     确保Mapper接口有@Mapper注解

3 事务问题

如果批量操作出现不一致，检查：
@Service注解是否添加
@Transactional注解是否配置正确

本文通过完整的案例演示了Spring Boot整合MyBatis的实现过程：

  1. 配置整合：通过starter简化配置
  2. 实体映射：使用MyBatis注解和XML双方式
  3. 数据操作：实现完整CRUD
  4. 分页查询：集成PageHelper插件
  5. 事务管理：使用声明式事务

这种整合方案在实际项目中应用广泛,具有：

  • 开发效率高
  • 性能优异
  • 维护方便
  • 社区活跃

建议在实际开发中结合代码生成工具（如MyBatis Generator）进一步提高开发效率。

上一篇Java Boot定时任务案例怎么开发

下一篇Java Boot整合Redis案例如何做

相关文章

抱歉，评论功能暂时关闭!
