PHP项目Subgraph与查询

使用Neo4j图数据库进行子图查询
使用Cypher查询语言进行复杂子图查询
使用RedisGraph（Redis模块）
使用纯PHP实现内存子图查询
使用Neo4j PHP ODM（对象文档映射）
性能优化建议
可视化子图

在PHP项目中进行子图（Subgraph）查询通常涉及图数据库（如Neo4j、ArangoDB、JanusGraph等）或图结构数据的处理,以下是一些常见场景和实现方式：

使用Neo4j图数据库进行子图查询

安装依赖

composer require graphaware/neo4j-php-client

查询示例

<?php
require_once 'vendor/autoload.php';
use GraphAware\Neo4j\Client\ClientBuilder;
// 连接Neo4j
$client = ClientBuilder::create()
    ->addConnection('default', 'http://neo4j:password@localhost:7474')
    ->build();
// 查询子图：找到特定节点的所有直接关联节点和关系
$query = '
MATCH (n:Person {name: {name}})
OPTIONAL MATCH (n)-[r]-(connected)
RETURN n, r, connected
';
$result = $client->run($query, ['name' => 'Alice']);
$nodes = [];
$edges = [];
foreach ($result->getRecords() as $record) {
    $node = $record->get('n');
    $nodes[] = [
        'id' => $node->identity(),
        'labels' => $node->labels(),
        'properties' => $node->values()
    ];
    $relationship = $record->get('r');
    if ($relationship) {
        $edges[] = [
            'id' => $relationship->identity(),
            'type' => $relationship->type(),
            'start' => $relationship->startNodeIdentity(),
            'end' => $relationship->endNodeIdentity()
        ];
    }
}
// 组合成子图结构
$subgraph = [
    'nodes' => $nodes,
    'edges' => $edges
];

使用Cypher查询语言进行复杂子图查询

多级子图查询

// 查询2层深度的子图
$query = '
MATCH (n:Person {name: {name}})
CALL apoc.path.subgraphAll(n, {
    maxLevel: 2,
    relationshipFilter: "KNOWS|WORKS_WITH"
}) YIELD nodes, relationships
RETURN nodes, relationships
';

使用RedisGraph（Redis模块）

安装和配置

composer require predis/predis

RedisGraph查询

<?php
use Predis\Client;
$redis = new Client([
    'scheme' => 'tcp',
    'host'   => 'localhost',
    'port'   => 6379,
]);
// 创建图
$redis->executeRaw(['GRAPH.CREATE', 'social_graph']);
// 添加节点和关系
$redis->executeRaw([
    'GRAPH.QUERY',
    'social_graph',
    "CREATE (:Person {name:'Alice', age:30})-[:KNOWS]->(:Person {name:'Bob', age:25})"
]);
// 查询子图
$result = $redis->executeRaw([
    'GRAPH.QUERY',
    'social_graph',
    "MATCH (a:Person {name:'Alice'})-[*1..2]-(connected) RETURN a, connected"
]);
var_dump($result);

使用纯PHP实现内存子图查询

<?php
class SubgraphManager {
    private $adjacencyList = [];
    public function addEdge($from, $to, $type = 'connected') {
        $this->adjacencyList[$from][$to] = ['type' => $type, 'weight' => 1];
        $this->adjacencyList[$to][$from] = ['type' => $type, 'weight' => 1];
    }
    /**
     * BFS查询子图
     */
    public function getSubgraph($startNode, $maxDepth = 1) {
        $visited = [$startNode => true];
        $queue = [[$startNode, 0]];
        $nodes = [$startNode];
        $edges = [];
        while ($queue) {
            [$current, $depth] = array_shift($queue);
            if ($depth >= $maxDepth) continue;
            if (isset($this->adjacencyList[$current])) {
                foreach ($this->adjacencyList[$current] as $neighbor => $relation) {
                    if (!isset($visited[$neighbor])) {
                        $visited[$neighbor] = true;
                        $nodes[] = $neighbor;
                        $edges[] = [
                            'from' => $current,
                            'to' => $neighbor,
                            'type' => $relation['type']
                        ];
                        $queue[] = [$neighbor, $depth + 1];
                    }
                }
            }
        }
        return [
            'nodes' => array_unique($nodes),
            'edges' => $edges
        ];
    }
}
// 使用示例
$graph = new SubgraphManager();
$graph->addEdge('Alice', 'Bob', 'friend');
$graph->addEdge('Bob', 'Charlie', 'colleague');
$graph->addEdge('Alice', 'David', 'family');
$subgraph = $graph->getSubgraph('Alice', 2);
print_r($subgraph);

使用Neo4j PHP ODM（对象文档映射）

<?php
use Neo4j\Neo4jBundle;
use GraphAware\Neo4j\Client\Formatter\Type\Node;
class UserRepository {
    public function findSubgraph(User $user, int $depth = 2) {
        $query = '
            MATCH (user:User {id: {userId}})
            CALL apoc.path.subgraphAll(user, {
                maxLevel: {depth},
                relationshipFilter: "FOLLOWS|FRIEND"
            }) YIELD nodes, relationships
            RETURN nodes, relationships
        ';
        $result = $this->client->run($query, [
            'userId' => $user->getId(),
            'depth' => $depth
        ]);
        // 处理结果...
    }
}

性能优化建议

索引创建

// Neo4j中创建索引
$client->run('CREATE INDEX ON :Person(name)');
$client->run('CREATE INDEX ON :Company(id)');

分页和限制

// 限制子图大小
$query = '
MATCH (n:Person {name: {name}})
CALL apoc.path.subgraphAll(n, {
    maxLevel: 2,
    limit: 100
}) YIELD nodes, relationships
RETURN nodes, relationships
';

缓存结果

// 使用Redis缓存子图查询结果
$cacheKey = "subgraph:{$name}:{$depth}";
$cached = $redis->get($cacheKey);
if ($cached) {
    return json_decode($cached, true);
}
// 执行查询...
$redis->setex($cacheKey, 3600, json_encode($subgraph));

可视化子图

<?php
function subgraphToVisJs($subgraph) {
    $nodes = [];
    $edges = [];
    foreach ($subgraph['nodes'] as $node) {
        $nodes[] = [
            'id' => $node['id'],
            'label' => $node['properties']['name'] ?? 'Node ' . $node['id'],
            'group' => $node['labels'][0] ?? 'default'
        ];
    }
    foreach ($subgraph['edges'] as $edge) {
        $edges[] = [
            'from' => $edge['start'],
            'to' => $edge['end'],
            'label' => $edge['type']
        ];
    }
    return json_encode(['nodes' => $nodes, 'edges' => $edges]);
}
header('Content-Type: application/json');
echo subgraphToVisJs($subgraphResult);

选择哪种方式取决于你的具体需求：
