Java安装包制作案例

项目准备
简单示例程序
使用Maven构建插件（推荐）
启动脚本
使用install4j制作专业安装包
使用JLink构建自定义运行时（Java 9+）
配置Windows服务
安装脚本示例
构建命令总结

我来为您提供一个完整的Java安装包制作案例,包含详细步骤和代码示例。

项目准备

项目结构

myapp/
├── src/
│   └── com/example/
│       └── MainApplication.java
├── resources/
│   ├── images/
│   └── config/
├── lib/
└── dist/

简单示例程序

// MainApplication.java
package com.example;
import javax.swing.*;
import java.awt.*;
import java.awt.event.ActionEvent;
public class MainApplication extends JFrame {
    public MainApplication() {
        setTitle("Java应用程序");
        setSize(400, 300);
        setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
        setLocationRelativeTo(null);
        // 创建主面板
        JPanel panel = new JPanel();
        panel.setLayout(new BorderLayout());
        // 添加标签
        JLabel label = new JLabel("欢迎使用Java应用!", SwingConstants.CENTER);
        label.setFont(new Font("微软雅黑", Font.BOLD, 18));
        panel.add(label, BorderLayout.CENTER);
        // 添加按钮
        JButton button = new JButton("点击我");
        button.addActionListener((ActionEvent e) -> {
            JOptionPane.showMessageDialog(this, "按钮被点击了!");
        });
        panel.add(button, BorderLayout.SOUTH);
        add(panel);
    }
    public static void main(String[] args) {
        SwingUtilities.invokeLater(() -> {
            new MainApplication().setVisible(true);
        });
    }
}

使用Maven构建插件（推荐）

pom.xml配置

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.example</groupId>
    <artifactId>my-app</artifactId>
    <version>1.0.0</version>
    <packaging>jar</packaging>
    <properties>
        <maven.compiler.source>11</maven.compiler.source>
        <maven.compiler.target>11</maven.compiler.target>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
    </properties>
    <build>
        <finalName>myapp</finalName>
        <plugins>
            <!-- 打包可执行Jar -->
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-jar-plugin</artifactId>
                <version>3.2.0</version>
                <configuration>
                    <archive>
                        <manifest>
                            <mainClass>com.example.MainApplication</mainClass>
                            <addClasspath>true</addClasspath>
                            <classpathPrefix>lib/</classpathPrefix>
                        </manifest>
                    </archive>
                </configuration>
            </plugin>
            <!-- 复制依赖到lib目录 -->
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-dependency-plugin</artifactId>
                <version>3.1.2</version>
                <executions>
                    <execution>
                        <id>copy-dependencies</id>
                        <phase>package</phase>
                        <goals>
                            <goal>copy-dependencies</goal>
                        </goals>
                        <configuration>
                            <outputDirectory>${project.build.directory}/lib</outputDirectory>
                            <includeScope>runtime</includeScope>
                        </configuration>
                    </execution>
                </executions>
            </plugin>
            <!-- 生成安装配置 -->
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-assembly-plugin</artifactId>
                <version>3.3.0</version>
                <configuration>
                    <descriptors>
                        <descriptor>src/assembly/package.xml</descriptor>
                    </descriptors>
                </configuration>
                <executions>
                    <execution>
                        <id>make-assembly</id>
                        <phase>package</phase>
                        <goals>
                            <goal>single</goal>
                        </goals>
                    </execution>
                </executions>
            </plugin>
        </plugins>
    </build>
</project>

Assembly描述文件

<!-- src/assembly/package.xml -->
<assembly xmlns="http://maven.apache.org/ASSEMBLY/2.0.0"
          xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
          xsi:schemaLocation="http://maven.apache.org/ASSEMBLY/2.0.0
          http://maven.apache.org/xsd/assembly-2.0.0.xsd">
    <id>dist</id>
    <formats>
        <format>zip</format>
        <format>tar.gz</format>
    </formats>
    <fileSets>
        <!-- 包含启动脚本 -->
        <fileSet>
            <directory>src/scripts</directory>
            <outputDirectory>/bin</outputDirectory>
            <includes>
                <include>*.sh</include>
                <include>*.bat</include>
            </includes>
            <fileMode>0755</fileMode>
        </fileSet>
        <!-- 包含配置文件 -->
        <fileSet>
            <directory>src/config</directory>
            <outputDirectory>/config</outputDirectory>
        </fileSet>
        <!-- 包含资源文件 -->
        <fileSet>
            <directory>src/main/resources</directory>
            <outputDirectory>/resources</outputDirectory>
        </fileSet>
        <!-- 包含主程序 -->
        <fileSet>
            <directory>${project.build.directory}</directory>
            <outputDirectory>/lib</outputDirectory>
            <includes>
                <include>*.jar</include>
            </includes>
        </fileSet>
        <!-- 包含依赖 -->
        <fileSet>
            <directory>${project.build.directory}/lib</directory>
            <outputDirectory>/lib</outputDirectory>
            <excludes>
                <exclude>myapp.jar</exclude>
            </excludes>
        </fileSet>
    </fileSets>
</assembly>

启动脚本

Linux/Mac启动脚本 (run.sh)

#!/bin/bash
# Java应用启动脚本
APP_NAME="myapp"
APP_HOME="$(cd "$(dirname "$0")/.." && pwd)"
JAVA_OPTS="-Xms256m -Xmx512m"
# 设置JAVA_HOME（如果没有配置）
if [ -z "$JAVA_HOME" ]; then
    JAVA_HOME="/usr/lib/jvm/java-11"
fi
# 构建classpath
CP="$APP_HOME/lib/*:$APP_HOME/resources"
# 启动应用
echo "Starting $APP_NAME..."
exec $JAVA_HOME/bin/java $JAVA_OPTS -cp "$CP" com.example.MainApplication "$@"

Windows启动脚本 (run.bat)

@echo off
setlocal
REM Java应用启动脚本
set APP_HOME=%~dp0..
set JAVA_OPTS=-Xms256m -Xmx512m
REM 设置JAVA_HOME（如果没有配置）
if "%JAVA_HOME%"=="" (
    set JAVA_HOME=C:\Program Files\Java\jdk-11
)
REM 构建classpath
set CP=%APP_HOME%\lib\*;%APP_HOME%\resources
REM 启动应用
echo Starting myapp...
"%JAVA_HOME%\bin\java" %JAVA_OPTS% -cp "%CP%" com.example.MainApplication %*
endlocal

使用install4j制作专业安装包

安装4j项目配置示例

<?xml version="1.0" encoding="UTF-8"?>
<install4j>
    <application name="MyApp"
                 version="1.0.0"
                 publisher="My Company">
        <screens>
            <welcomeScreen/>
            <licenseScreen>
                <file>licenses/LICENSE.txt</file>
            </licenseScreen>
            <installationDirectoryScreen/>
            <installationTypeScreen/>
            <confirmInstallationScreen/>
            <finishedScreen/>
        </screens>
        <launchers>
            <launcher name="MyApp" id="custom">
                <executableName>myapp</executableName>
                <icon>icons/app.ico</icon>
                <mainClass>com.example.MainApplication</mainClass>
                <splashScreen>
                    <image>images/splash.png</image>
                </splashScreen>
                <jreLocation>jre</jreLocation>
                <vmOptions>
                    <option>-Xmx512m</option>
                    <option>-Dfile.encoding=UTF-8</option>
                </vmOptions>
            </launcher>
        </launchers>
        <components>
            <component id="application">
                <files>
                    <file>
                        <source>dist/myapp.jar</source>
                        <dest>lib/myapp.jar</dest>
                    </file>
                </files>
            </component>
        </components>
        <installerOptions>
            <requiredInstallerVersion>5.0</requiredInstallerVersion>
            <friendlyName>My Application Installer</friendlyName>
            <fileName>myapp-setup</fileName>
            <!-- 自动生成快捷方式 -->
            <shortcuts>
                <shortcut name="MyApp"
                         shortcutType="desktop_and_start_menu"
                         launcherId="custom"/>
            </shortcuts>
            <!-- 关联文件类型 -->
            <fileAssociations>
                <fileAssociation name="MyApp File"
                               extensions="myapp"
                               launcherId="custom"/>
            </fileAssociations>
        </installerOptions>
    </application>
</install4j>

使用JLink构建自定义运行时（Java 9+）

# 1. 构建模块化应用
javac -d mods/com.example $(find src -name "*.java")
# 2. 创建模块描述文件
cat > mods/com.example/module-info.java << EOF
module com.example {
    requires java.desktop;
    exports com.example;
}
EOF
# 3. 构建自定义JRE
jlink \
    --module-path mods:$JAVA_HOME/jmods \
    --add-modules com.example,java.desktop \
    --output myapp-runtime \
    --launcher myapp=com.example/com.example.MainApplication \
    --compress=2 \
    --strip-debug \
    --no-header-files \
    --no-man-pages
# 4. 打包分发包
tar -czf myapp-linux-x64.tar.gz myapp-runtime/
# 或使用jpackage（Java 14+）
jpackage \
    --input target \
    --name MyApp \
    --main-jar myapp.jar \
    --main-class com.example.MainApplication \
    --type app-image \
    --icon app.ico \
    --vendor "My Company" \
    --app-version 1.0.0

配置Windows服务

<!-- 使用WinSW配置Windows服务 -->
<service>
    <id>myapp</id>
    <name>MyApp Service</name>
    <description>Java Application Service</description>
    <executable>java</executable>
    <arguments>-Xmx512m -jar "%BASE%\lib\myapp.jar"</arguments>
    <logmode>rotate</logmode>
</service>

安装脚本示例

Linux安装脚本

#!/bin/bash
# 安装Java应用
APP_NAME="myapp"
INSTALL_DIR="/opt/$APP_NAME"
VERSION="1.0.0"
echo "Installing $APP_NAME v$VERSION..."
# 创建安装目录
mkdir -p $INSTALL_DIR
mkdir -p $INSTALL_DIR/bin
mkdir -p $INSTALL_DIR/lib
mkdir -p $INSTALL_DIR/config
mkdir -p $INSTALL_DIR/logs
# 复制文件
cp -r dist/* $INSTALL_DIR/
cp -r config/* $INSTALL_DIR/config/
# 创建启动脚本
cat > /usr/local/bin/myapp << EOF
#!/bin/bash
exec $INSTALL_DIR/bin/run.sh "\$@"
EOF
chmod +x /usr/local/bin/myapp
# 设置权限
chown -R root:root $INSTALL_DIR
chmod -R 755 $INSTALL_DIR
echo "Installation completed!"
echo "Run 'myapp' to start the application"

Windows安装打包 (NSIS)

; NSIS安装脚本示例
!include "MUI2.nsh"
!define PRODUCT_NAME "Java Application"
!define VERSION "1.0.0"
!define INSTALL_DIR "$PROGRAMFILES\JavaApp"
Name "${PRODUCT_NAME}"
OutFile "JavaAppSetup.exe"
InstallDir "${INSTALL_DIR}"
!insertmacro MUI_PAGE_WELCOME
!insertmacro MUI_PAGE_DIRECTORY
!insertmacro MUI_PAGE_INSTFILES
!insertmacro MUI_PAGE_FINISH
!insertmacro MUI_LANGUAGE "SimplifiedChinese"
Section "MainSection" SEC01
    SetOutPath "$INSTDIR"
    ; 复制应用文件
    File /r "dist\*"
    File /r "config\*"
    ; 创建开始菜单快捷方式
    CreateDirectory "$SMPROGRAMS\${PRODUCT_NAME}"
    CreateShortCut "$SMPROGRAMS\${PRODUCT_NAME}\${PRODUCT_NAME}.lnk" \
                   "$INSTDIR\bin\run.bat"
    ; 创建桌面快捷方式
    CreateShortCut "$DESKTOP\${PRODUCT_NAME}.lnk" \
                   "$INSTDIR\bin\run.bat"
    ; 注册卸载信息
    WriteUninstaller "$INSTDIR\uninstall.exe"
    WriteRegStr HKLM "Software\Microsoft\Windows\CurrentVersion\Uninstall\${PRODUCT_NAME}" \
             "DisplayName" "${PRODUCT_NAME}"
    WriteRegStr HKLM "Software\Microsoft\Windows\CurrentVersion\Uninstall\${PRODUCT_NAME}" \
             "UninstallString" "$INSTDIR\uninstall.exe"
SectionEnd
Section "Uninstall"
    Delete "$INSTDIR\uninstall.exe"
    RMDir /r "$INSTDIR"
    Delete "$SMPROGRAMS\${PRODUCT_NAME}\${PRODUCT_NAME}.lnk"
    RMDir "$SMPROGRAMS\${PRODUCT_NAME}"
    Delete "$DESKTOP\${PRODUCT_NAME}.lnk"
    DeleteRegKey HKLM "Software\Microsoft\Windows\CurrentVersion\Uninstall\${PRODUCT_NAME}"
SectionEnd

构建命令总结

# 1. Maven构建
mvn clean package
# 2. 生成安装包目录结构
cd target
mkdir -p myapp-1.0.0/bin
mkdir -p myapp-1.0.0/lib
mkdir -p myapp-1.0.0/config
# 3. 复制文件
cp myapp.jar lib/
cp -r lib/ myapp-1.0.0/lib/
cp bin/run.sh bin/run.bat myapp-1.0.0/bin/
cp config/* myapp-1.0.0/config/
# 4. 打包
tar -czf myapp-1.0.0-linux.tar.gz myapp-1.0.0/
zip -r myapp-1.0.0-windows.zip myapp-1.0.0/

这个案例覆盖了Java应用打包的主要方式,您可以根据需求选择适合的方案，对于简单应用，建议使用Maven + 启动脚本；对于企业级应用，推荐使用install4j或jpackage。
