我来详细讲解Python实现数据聚类的几种常用方法,并附带完整案例。

准备环境

# 安装必要的库
# pip install numpy pandas matplotlib scikit-learn
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from sklearn.datasets import make_blobs
from sklearn.cluster import KMeans, DBSCAN, AgglomerativeClustering
from sklearn.preprocessing import StandardScaler
from sklearn.metrics import silhouette_score

生成示例数据

# 生成模拟数据
X, y_true = make_blobs(n_samples=300, centers=4,
                       cluster_std=0.60, random_state=0)
# 可视化原始数据
plt.figure(figsize=(8, 6))
plt.scatter(X[:, 0], X[:, 1], s=50)'原始数据分布')
plt.xlabel('特征1')
plt.ylabel('特征2')
plt.show()

K-Means聚类

# K-Means聚类
kmeans = KMeans(n_clusters=4, random_state=0)
kmeans_labels = kmeans.fit_predict(X)
kmeans_centers = kmeans.cluster_centers_
# 可视化结果
plt.figure(figsize=(12, 4))
plt.subplot(1, 2, 1)
plt.scatter(X[:, 0], X[:, 1], c=kmeans_labels, cmap='viridis', s=50)
plt.scatter(kmeans_centers[:, 0], kmeans_centers[:, 1],
            marker='x', s=200, linewidths=3, color='red')'K-Means聚类结果')
plt.xlabel('特征1')
plt.ylabel('特征2')
# 肘部法则确定最佳K值
inertias = []
K_range = range(1, 11)
for k in K_range:
    kmeans_temp = KMeans(n_clusters=k, random_state=0)
    kmeans_temp.fit(X)
    inertias.append(kmeans_temp.inertia_)
plt.subplot(1, 2, 2)
plt.plot(K_range, inertias, 'bo-')
plt.xlabel('K值')
plt.ylabel('惯性值')'肘部法则')
plt.tight_layout()
plt.show()
print(f"K-Means轮廓系数: {silhouette_score(X, kmeans_labels):.3f}")

DBSCAN聚类

# DBSCAN聚类
dbscan = DBSCAN(eps=0.3, min_samples=5)
dbscan_labels = dbscan.fit_predict(X)
# 可视化结果
plt.figure(figsize=(12, 4))
plt.subplot(1, 2, 1)
plt.scatter(X[:, 0], X[:, 1], c=dbscan_labels, cmap='viridis', s=50)'DBSCAN聚类结果')
plt.xlabel('特征1')
plt.ylabel('特征2')
# 参数调优：不同eps值的效果
eps_values = [0.1, 0.3, 0.5, 0.7]
plt.subplot(1, 2, 2)
for eps in eps_values:
    dbscan_temp = DBSCAN(eps=eps, min_samples=5)
    labels_temp = dbscan_temp.fit_predict(X)
    n_clusters = len(set(labels_temp)) - (1 if -1 in labels_temp else 0)
    n_noise = list(labels_temp).count(-1)
    print(f"eps={eps}: 聚类数={n_clusters}, 噪声点={n_noise}")
plt.tight_layout()
plt.show()

层次聚类

# 层次聚类
agg_clustering = AgglomerativeClustering(n_clusters=4)
agg_labels = agg_clustering.fit_predict(X)
# 可视化
plt.figure(figsize=(12, 4))
plt.subplot(1, 2, 1)
plt.scatter(X[:, 0], X[:, 1], c=agg_labels, cmap='viridis', s=50)'层次聚类结果')
plt.xlabel('特征1')
plt.ylabel('特征2')
# 创建树状图
from scipy.cluster.hierarchy import dendrogram, linkage
plt.subplot(1, 2, 2)
linked = linkage(X, 'ward')
dendrogram(linked, truncate_mode='level', p=5)'层次聚类树状图')
plt.xlabel('样本索引')
plt.ylabel('距离')
plt.tight_layout()
plt.show()

完整聚类分析流程

class ClusterAnalyzer:
    """聚类分析器"""
    def __init__(self, data):
        self.data = data
        self.scaler = StandardScaler()
        self.scaled_data = None
        self.results = {}
    def preprocess(self):
        """数据预处理"""
        self.scaled_data = self.scaler.fit_transform(self.data)
        return self
    def kmeans_analysis(self, k_range=range(2, 11)):
        """K-Means完整分析"""
        results = []
        for k in k_range:
            kmeans = KMeans(n_clusters=k, random_state=0)
            labels = kmeans.fit_predict(self.scaled_data)
            silhouette = silhouette_score(self.scaled_data, labels)
            results.append({
                'k': k,
                'inertia': kmeans.inertia_,
                'silhouette': silhouette
            })
        self.results['kmeans'] = results
        return self.plot_results(results, 'K-Means')
    def plot_results(self, results, title):
        """绘制分析结果"""
        fig, axes = plt.subplots(1, 2, figsize=(12, 4))
        ks = [r['k'] for r in results]
        inertias = [r['inertia'] for r in results]
        silhouettes = [r['silhouette'] for r in results]
        axes[0].plot(ks, inertias, 'bo-')
        axes[0].set_xlabel('K值')
        axes[0].set_ylabel('惯性值')
        axes[0].set_title(f'{title} - 肘部法则')
        axes[1].plot(ks, silhouettes, 'ro-')
        axes[1].set_xlabel('K值')
        axes[1].set_ylabel('轮廓系数')
        axes[1].set_title(f'{title} - 轮廓系数')
        plt.tight_layout()
        plt.show()
        best_k = ks[np.argmax(silhouettes)]
        print(f"最佳K值: {best_k} (轮廓系数: {max(silhouettes):.3f})")
        return best_k
# 使用完整分析流程
analyzer = ClusterAnalyzer(X)
analyzer.preprocess()
best_k = analyzer.kmeans_analysis()

实战：客户分群案例

# 生成客户数据
np.random.seed(42)
n_customers = 200
data = {
    '年龄': np.random.randint(18, 65, n_customers),
    '收入': np.random.normal(50000, 20000, n_customers),
    '消费金额': np.random.normal(2000, 800, n_customers),
    '购物频率': np.random.randint(1, 30, n_customers)
}
df = pd.DataFrame(data)
# 数据标准化
scaler = StandardScaler()
scaled_data = scaler.fit_transform(df[['收入', '消费金额']])
# K-Means聚类
kmeans = KMeans(n_clusters=3, random_state=0)
df['客户类别'] = kmeans.fit_predict(scaled_data)
# 分析结果
print("\n客户分群统计：")
for cluster in range(3):
    cluster_data = df[df['客户类别'] == cluster]
    print(f"\n类别 {cluster}:")
    print(f"  数量: {len(cluster_data)}")
    print(f"  平均年龄: {cluster_data['年龄'].mean():.1f}")
    print(f"  平均收入: {cluster_data['收入'].mean():.0f}")
    print(f"  平均消费: {cluster_data['消费金额'].mean():.0f}")
    print(f"  购物频率: {cluster_data['购物频率'].mean():.1f}")
# 可视化
plt.figure(figsize=(10, 6))
scatter = plt.scatter(df['收入'], df['消费金额'],
                     c=df['客户类别'], cmap='viridis', s=50)
plt.xlabel('收入')
plt.ylabel('消费金额')'客户分群结果')
plt.colorbar(scatter)
plt.show()

聚类效果评估

def evaluate_clustering(X, labels, algorithm_name):
    """评估聚类效果"""
    from sklearn.metrics import silhouette_score, calinski_harabasz_score, davies_bouldin_score
    n_clusters = len(set(labels)) - (1 if -1 in labels else 0)
    print(f"\n{algorithm_name} 评估结果:")
    print(f"聚类数量: {n_clusters}")
    if n_clusters > 1:
        silhouette = silhouette_score(X, labels)
        ch_score = calinski_harabasz_score(X, labels)
        db_score = davies_bouldin_score(X, labels)
        print(f"轮廓系数: {silhouette:.3f}")
        print(f"Calinski-Harabasz分数: {ch_score:.3f}")
        print(f"Davies-Bouldin分数: {db_score:.3f}")
        # 判断标准
        if silhouette > 0.5:
            print(" 聚类效果良好")
        elif silhouette > 0.25:
            print(" 聚类效果一般")
        else:
            print(" 聚类效果较差")
    else:
        print("需要多个聚类才能进行效果评估")
# 评估不同聚类算法
print("="*50)
print("聚类算法对比评估")
print("="*50)
evaluate_clustering(X, kmeans_labels, "K-Means")
evaluate_clustering(X, dbscan_labels, "DBSCAN")
evaluate_clustering(X, agg_labels, "层次聚类")
